ALPHA3A/0.2M/MMCXM/S/S/26
£10.31
5G/4G/2.4GHz Wi-Fi, Bluetooth, Zigbee Adhesive Antenna MMCX Male 0.2M Cable
Supports 5G NR / 4G LTE / 2G Quad-Band GSM
Supports LTE Cat M, LTE Cat NB and NR Cat NB Bands
Supports 2.4 GHz applications: WiFi, Bluetooth,
Want to be notified when this product is back in stock?
Images are for illustrative purposes only.
Contact us for information regarding lead times and incoming stock.
- Description
- Additional information
- Reviews (0)
Description
The Alpha 3A multi band antenna is based on an efficiently tuned PCB element that is matched with a wide variety of RF & M2M modules, operating on quad band 2G, ISM and WiFi frequencies It is designed as a ready to go antenna which fits most telemetry products Already proven in many applications where space is at a premium, this product is ideal as it is ground plane independent and compact, making it a popular choice where the user does not want to draw attention to having telemetry equipment on board It connects via MMCXM with a lead length of 0 This Antenna can operate in temperatures from -40 to temperatures of 85 It has a gain of 2 and an impedance of 50 Ohm
Additional information
| Weight | 0.0866 kg |
|---|---|
| Mounting Style | Adhesive |
| Product Series | Alpha |
| Cable Length | 0.2m |
| Connector Type | MMCXM |
| Cellular Technology | 2G GSM, 3G UMTS, 4G LTE, 5G NR, LTE CAT-M, LTE NB-IoT |
| WiFi Technology | WiFi 4, WiFi 5G, WiFi 6 |
| Non-Cellular ISM Technology | Bluetooth, HNT Helium, ISM 2450, ISM 868, ISM 915, LoRa Wireless, Sigfox, Weightless, Z Wave, Zigbee |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
