OSCAR67/X/NTYPEF/33
£86.34
OSCAR67/X/NTYPEF/33 | High Gain 9 dBi Directional ISM Outdoor Panel Antenna for 868/915 MHz
Images are for illustrative purposes only.
Contact us for information regarding lead times and incoming stock.
- Description
- Additional information
- Reviews (0)
Description
OSCAR67
The OSCAR 67 from Siretta is a highly efficient wide beam directional antenna designed for use in the 868 and 915 MHz frequency bands With a peak gain of 9 dBi, a VSWR of 1 and the ability to handle up to 100 watts of power, this antenna is suitable for ISM, LoRa, Sigfox, Zigbee, Helium and Z-Wave applications
The antenna s radome is made of engineering grade ASA plastic and can be set up with vertical or horizontal polarization OSCAR 67 also comes with a wall mount and a pole mount, both are made of steel with an anti-rust treatment and can be adjusted to optimise signal strength
Key Features
700 – 900 MHz support
Supports IEEE 802 LoRa, Sigfox, Zigbee and Z-Wave and Helium bands
Wide beam-width directional coverage
Engineering grade ASA plastic radome
9 dBi gain
Applications
Remote sensor telemetry
Precision agriculture
Smart city applications
Additional information
| Weight | 1.2 kg |
|---|---|
| Mounting Style | Wall/Pole |
| Product Series | Oscar |
| Connector Type | N-TYPEF |
| Non-Cellular ISM Technology | HNT Helium, ISM 868, ISM 915, LoRa Wireless, Sigfox, Z Wave, Zigbee |
| Impedance (Ohm) | 50 |
| Polarisation | Linear, Vertical |
