TANGO41/5M/SMAM/S/S/33
£41.92
5G/4G/Dual Band Wi-Fi/LoRa/SigFox Panel Mount Antenna 5M Cable SMA Male Connector
5dBi gain at 4G/2600MHz
Outdoor rugged antenna
Integrated RF cable
IP65 Rated
Images are for illustrative purposes only.
Contact us for information regarding lead times and incoming stock.
- Description
- Additional information
- Reviews (0)
Description
The Tango 41 is a wide band outdoor antenna range aimed at the 5G dual band Wi-Fi frequencies but equally capable of ISM frequencies The antenna has a high peak gain of 7 dBi in the upper frequency band and 1-4 dBi peak performance in the mid and lower frequency band The Tango 41 has an integrated RF cable terminated with an SMA male connector and features and IP 65 rated O-ring seal for outdoor use and the prevention of water and dust ingress
Additional information
| Weight | 0.1228 kg |
|---|---|
| Mounting Style | Through Hole |
| Product Series | Tango |
| Cable Length | 5m |
| Connector Type | SMAM |
| Cellular Technology | 2G GSM, 3G UMTS, 4G LTE, 5G NR, LTE CAT-M, LTE NB-IoT |
| WiFi Technology | WiFi 4, WiFi 5, WiFi 6 |
| Non-Cellular ISM Technology | Bluetooth, HNT Helium, ISM 2450, ISM 5800, ISM 868, ISM 915, LoRa Wireless, Sigfox, Weightless, Zigbee |
| IP Rating | IP65 |
| Impedance (Ohm) | 50 |
| Polarisation | Vertical |
